一、回转窑用耐火砖尺寸号表示法
分五种：第一，等大端尺寸103mm回转窑用砖；
第二，等中间尺寸71.5mm回转窑用砖；
第三，等大端尺寸100mm回转窑用砖；
第四，等中间尺寸75mm回转窑用砖；
第五，回转窑专用锁砖；
二、回转窑耐火砖的尺寸组成
尺寸砖号由字母和数字组成，末两位数表示该砖大小端距离的厘米数，其前的数字表示该砖标称外直径的米数；由数字前无字母的表示等大端尺寸103mm砖、数字前有字母B表示等中间尺寸71.5mm砖。
三、回转窑耐火砖 尺寸规格表示法
回转窑用砖的尺寸规格以A*(C/D)*B表示， A, C/D和B的单位为毫米(mm)并可省去。
四、回转窑用耐火砖尺寸表
|
表1 等大端尺寸103mm回转窑用砖 |
||||||||
|
尺寸砖号 |
尺寸/mm |
单位楔差f |
外直径/mm |
每环砖极限数/块 |
体积/cm3 |
|||
|
A |
C/D |
B |
L=2(C+δ)/f |
K=2π/f |
||||
|
δ=1mm |
δ=2mm |
|||||||
|
216 |
160 |
103/86 |
198 |
0.1063 |
1957.6 |
1976.5 |
59.136 |
2993.8 |
|
316 |
103/92 |
0.0688 |
3025.5 |
3054.5 |
91.392 |
3088.8 |
||
|
416 |
103/94.5 |
0.0531 |
3915.3 |
3952.9 |
118.272 |
3128.4 |
||
|
516 |
103/96.5 |
0.0406 |
5120 |
5169.2 |
154.663 |
3160.1 |
||
|
716 |
103/98.5 |
0.0294 |
7080.9 |
7148.9 |
213.896 |
3188.6 |
||
|
218 |
180 |
103/84 |
198 |
0.1056 |
1970.5 |
1989.5 |
59.525 |
3332.3 |
|
318 |
103/90.5 |
0.0694 |
2995.2 |
3024 |
90.478 |
3448.2 |
||
|
418 |
103/93.5 |
0.0528 |
3941.1 |
3978.9 |
119.05 |
3501.6 |
||
|
518 |
103/95.5 |
0.0417 |
4992 |
5040 |
150.796 |
3537.3 |
||
|
618 |
103/97 |
0.0333 |
6240 |
6300 |
188.496 |
3564 |
||
|
718 |
103/97.7 |
0.0294 |
7064.2 |
7132.1 |
213.391 |
3576.5 |
||
|
220 |
200 |
103/82 |
198 |
0.1050 |
1981.0 |
2000.0 |
59.840 |
3663.0 |
|
320 |
103/89 |
0.0700 |
2971.4 |
3000.0 |
89.760 |
3801.6 |
||
|
420 |
103/92.5 |
0.0525 |
3961.9 |
4000.0 |
119.680 |
3870.9 |
||
|
520 |
103/94.7 |
0.0415 |
5012.0 |
5060.2 |
151.402 |
3914.5 |
||
|
620 |
103/96.2 |
0.0340 |
6117.6 |
6176.5 |
184.800 |
3944.2 |
||
|
720 |
103/97 |
0.0300 |
6933.3 |
7000.0 |
209.440 |
3960.0 |
||
|
820 |
103/97.8 |
0.0260 |
8000.0 |
8076.9 |
241.662 |
3975.8 |
||
|
322 |
220 |
103/88.0 |
198 |
0.0682 |
3050.7 |
3080.0 |
92.154 |
4160.0 |
|
422 |
103/91.5 |
0.0523 |
3979.1 |
4017.4 |
120.200 |
4236.2 |
||
|
522 |
103/94 |
0.0409 |
5084.4 |
5133.3 |
153.589 |
4290.7 |
||
|
622 |
103/95.5 |
0.0341 |
6101.3 |
6160.0 |
184.307 |
4323.3 |
||
|
722 |
103/96.5 |
0.0295 |
7040.0 |
7107.7 |
212.662 |
4345.1 |
||
|
822 |
103/97.3 |
0.0259 |
8028.1 |
8105.3 |
242.509 |
4362.5 |
||
|
425 |
250 |
103/90.0 |
198 |
0.0520 |
4000.0 |
4038.5 |
120.831 |
4776.8 |
|
525 |
103/92.7 |
0.0412 |
5048.5 |
5097.1 |
152.505 |
4843.6 |
||
|
625 |
103/94.5 |
0.0340 |
6117.6 |
6176.5 |
184.800 |
4888.1 |
||
|
725 |
103/95.5 |
0.0300 |
6933.3 |
7000.0 |
209.440 |
4912.9 |
||
|
825 |
103/96.5 |
0.0260 |
8000.0 |
8076.9 |
241.662 |
4937.6 |
||
|
备注：1.δ为砌筑的砖缝大小，单位mm；2.本表既适合碱性砖，又适合非碱性砖； |
||||||||
|
表2 等中间尺寸71.5mm回转窑用砖 |
||||||||
|
尺寸砖号 |
尺寸/mm |
单位楔差f |
外直径/mm |
每环砖极限数/块 |
体积/cm3 |
|||
|
A |
C/D |
B |
L=2(C+δ)/f |
K=2π/f |
||||
|
δ=1mm |
δ=2mm |
|||||||
|
B216 |
160 |
78.0/65.0 |
198 |
0.0813 |
2187.7 |
2215.4 |
86.998 |
2265.1 |
|
B416 |
75.0/68.0 |
0.0438 |
2790.0 |
2826.0 |
113.098 |
|||
|
B218 |
180 |
78.0/65.0 |
198 |
0.0722 |
3908.6 |
3960.0 |
161.568 |
2548.3 |
|
B318 |
76.5/66.5 |
0.0556 |
4530.0 |
4590.0 |
188.496 |
|||
|
B418 |
75.0/68.0 |
0.0389 |
5400.0 |
5472.0 |
226.195 |
|||
|
B518 |
74.5/68.5 |
0.0333 |
4992.0 |
5040.0 |
150.796 |
|||
|
B618 |
74.0/69.0 |
0.0278 |
6240.0 |
6300.0 |
188.496 |
|||
|
B220 |
200 |
78.0/65.0 |
198 |
0.0650 |
2430.8 |
2461.5 |
96.665 |
2831.4 |
|
B320 |
76.5/66.5 |
0.0500 |
3100.0 |
3140.0 |
125.664 |
|||
|
B420 |
75.0/68.0 |
0.0350 |
4342.9 |
4400.0 |
179.520 |
|||
|
B520 |
74.5/68.5 |
0.0300 |
5033.3 |
5100.0 |
209.440 |
|||
|
B620 |
74.0/69.0 |
0.0250 |
6000.0 |
6080.0 |
241.328 |
|||
|
B222 |
220 |
78.0/65.0 |
198 |
0.0591 |
2673.8 |
2707.7 |
106.331 |
3114.5 |
|
B322 |
76.5/66.5 |
0.0455 |
3410.0 |
3454.0 |
138.230 |
|||
|
B422 |
75.0/68.0 |
0.0318 |
4777.1 |
484.0 |
197.472 |
|||
|
B522 |
74.5/68.5 |
0.0273 |
5536.7 |
5610.0 |
230.384 |
|||
|
B622 |
74.0/69.0 |
0.0227 |
6600.0 |
6688.0 |
276.461 |
|||
|
B325 |
250 |
78.0/65.0 |
198 |
0.0520 |
3038.5 |
3076.9 |
120.831 |
3539.3 |
|
B425 |
76.5/66.5 |
0.0400 |
3875.0 |
3925.0 |
157.080 |
|||
|
B525 |
75.0/68.0 |
0.0280 |
5428.6 |
5500.0 |
224.400 |
|||
|
B625 |
74.5/68.5 |
0.0240 |
6291.7 |
6375.0 |
261.800 |
|||
|
B725 |
74.0/69.0 |
0.0200 |
7500.0 |
7600.0 |
314.160 |
|||
|
备注：1.δ为砌筑的砖缝大小，单位mm；2.本表既适合碱性砖，又适合非碱性砖； |
||||||||
|
表3 等大端尺寸100mm回转窑用砖 |
||||||||
|
尺寸砖号 |
尺寸/mm |
单位楔差f |
外直径/mm |
每环砖极限数/块 |
体积/cm3 |
|||
|
A |
C/D |
B |
L=2(C+δ)/f |
K=2π/f |
||||
|
δ=1mm |
δ=2mm |
|||||||
|
H16-100/85.0 |
160 |
100/85.0 |
198 |
0.0938 |
2154.7 |
2176.0 |
67.021 |
2930.4 |
|
H16-100/90.0 |
100/90.0 |
0.0625 |
3232.0 |
3264.0 |
100.531 |
3009.6 |
||
|
H16-100/92.5 |
100/92.5 |
0.0469 |
4309.3 |
4352.0 |
134.042 |
3049.2 |
||
|
H16-100/95.0 |
100/95.0 |
0.0313 |
6464.0 |
6528.0 |
201.062 |
3088.8 |
||
|
H18-100/85.0 |
180 |
100/85.0 |
198 |
0.0833 |
2424.0 |
2448.0 |
75.398 |
3663.0 |
|
H18-100/90.0 |
100/90.0 |
0.0556 |
3636.0 |
3672.0 |
113.098 |
3762.0 |
||
|
H18-100/92.5 |
100/92.5 |
0.0417 |
4848.0 |
4896.0 |
150.797 |
3811.5 |
||
|
H18-100/95.0 |
100/95.0 |
0.0278 |
7272.0 |
7344.0 |
226.195 |
3861.0 |
||
|
H20-100/85.0 |
200 |
100/85.0 |
198 |
0.0750 |
2693.3 |
2720.0 |
83.776 |
4029.3 |
|
H20-100/90.0 |
100/90.0 |
0.0500 |
4040.0 |
4080.0 |
125.664 |
4138.2 |
||
|
H20-100/92.5 |
100/92.5 |
0.0375 |
5386.7 |
5440.0 |
167.552 |
4192.7 |
||
|
H20-100/95.0 |
100/95.0 |
0.0250 |
8080.0 |
8160.0 |
251.328 |
4247.1 |
||
|
H22-100/85.0 |
220 |
100/85.0 |
198 |
0.0682 |
2962.7 |
2992.0 |
92.154 |
4029.3 |
|
H22-100/90.0 |
100/90.0 |
0.0455 |
4444.0 |
4488.0 |
138.230 |
4138.2 |
||
|
H22-100/92.5 |
100/92.5 |
0.0341 |
5925.3 |
5984.0 |
184.307 |
4192.7 |
||
|
H22-100/95.0 |
100/95.0 |
0.0227 |
8888.0 |
8976.0 |
276.461 |
4247.1 |
||
|
H25-100/85.0 |
250 |
100/85.0 |
198 |
0.0600 |
3366.7 |
3400.0 |
104.720 |
4578.8 |
|
H25-100/90.0 |
100/90.0 |
0.0400 |
5050.0 |
5100.0 |
157.080 |
4702.5 |
||
|
H25-100/92.5 |
100/92.5 |
0.0300 |
6733.3 |
6800.0 |
209.440 |
4764.4 |
||
|
H25-100/95.0 |
100/95.0 |
0.0200 |
10100.0 |
10200.0 |
314.160 |
4826.3 |
||
|
备注：1.δ为砌筑的砖缝大小，单位mm；2.本表既适合碱性砖，又适合非碱性砖；等大端尺寸 |
||||||||
|
表4 等中间尺寸75mm回转窑用砖 |
||||||||
|
尺寸砖号 |
尺寸/mm |
单位楔差f |
外直径/mm |
每环砖极限数/块 |
体积/cm3 |
|||
|
A |
C/D |
B |
L=2(C+δ)/f |
K=2π/f |
||||
|
δ=1mm |
δ=2mm |
|||||||
|
H16-82.5/67.5 |
160 |
82.5/67.5 |
198 |
0.0938 |
1781.3 |
1802.7 |
67.021 |
2376.0 |
|
H16-80.0/70.0 |
80.0/70.0 |
0.0625 |
2592.0 |
2624.0 |
100.531 |
|||
|
H16-78.8/71.3 |
78.8/71.3 |
0.0469 |
3402.7 |
3445.3 |
134.042 |
|||
|
H16-77.5/72.5 |
77.5/72.5 |
0.0313 |
5024.0 |
5088.0 |
201.062 |
|||
|
H18-82.5/67.5 |
180 |
82.5/67.5 |
198 |
0.0833 |
2004.0 |
2028.0 |
75.398 |
2673.0 |
|
H18-80.0/70.0 |
80.0/70.0 |
0.0556 |
2916.0 |
2952.0 |
113.098 |
|||
|
H18-78.8/71.3 |
78.8/71.3 |
0.0417 |
3828.0 |
3876.0 |
150.797 |
|||
|
H18-77.5/72.5 |
77.5/72.5 |
0.0278 |
5652.0 |
5724.0 |
226.195 |
|||
|
H20-82.5/67.5 |
200 |
82.5/67.5 |
198 |
0.0750 |
2226.7 |
2253.3 |
83.776 |
2970.0 |
|
H20-80.0/70.0 |
80.0/70.0 |
0.0500 |
3240.0 |
3280.0 |
125.664 |
|||
|
H20-78.8/71.3 |
78.8/71.3 |
0.0375 |
4253.3 |
4306.7 |
167.552 |
|||
|
H20-77.5/72.5 |
77.5/72.5 |
0.0250 |
6280.0 |
6360.0 |
251.328 |
|||
|
H22-82.5/67.5 |
220 |
82.5/67.5 |
198 |
0.0682 |
2449.3 |
2478.7 |
92.154 |
3267.0 |
|
H22-80.0/70.0 |
80.0/70.0 |
0.0455 |
3564.0 |
3608.0 |
138.230 |
|||
|
H22-78.8/71.3 |
78.8/71.3 |
0.0341 |
4678.7 |
4737.3 |
184.307 |
|||
|
H22-77.5/72.5 |
77.5/72.5 |
0.0227 |
6908.0 |
6996.0 |
276.461 |
|||
|
H25-82.5/67.5 |
250 |
82.5/67.5 |
198 |
0.0600 |
2783.3 |
2816.7 |
104.720 |
3712.5 |
|
H25-80.0/70.0 |
80.0/70.0 |
0.0400 |
4050.0 |
4100.0 |
157.080 |
|||
|
H25-78.8/71.3 |
78.8/71.3 |
0.0300 |
5316.7 |
5383.3 |
209.440 |
|||
|
H25-77.5/72.5 |
77.5/72.5 |
0.0200 |
7850.0 |
7950.0 |
314.160 |
|||
|
备注：1.δ为砌筑的砖缝大小，单位mm；2.本表既适合碱性砖，又适合非碱性砖； |
||||||||
